Notes (Male):

1. Material:

   NdFeB magnet

   Housing: HTN+30% UL94 V-0

   Brass C3604 Plating: Gold Plated over Nickel

2. Electrical

   2.1 Current rated: 2.0A per pin

   2.2 Voltage rated: 12 V

   2.3 80+/-20g Working @ 1.0mm stroke

   2.4 Contact Resistance: 30m OHm Max (Pin)

   2.5 AC1000V 0.5mA 3 Sec/DC1000V 0.5mA 3 Sec

   2.6 Life time: 50000 cycles

3. Magnetic Force: Above 180g

4. RoHS,REACH,CP65 compliant
