Materials:

Contact plunger&base:Machined copper alloy plated 0.025μm gold over 0.075μm nickel

Spring:Stainless steel SUS304

Insulator:High temperature thermoplastic,rated UL94V-0

Mechanical:

Spring force:70+20 grams

Durability:10000 cycles

Electrical:

Voltage rating:12V

Current rating:1A(continous)

Contact resistance:50mOHm Max

Reflow Soldering:260℃ Max
